TEXAS INSTRUMENTS  MSP-EXP430G2  Integrated USB-powered Flash Emulation Tool, MSP430G2XX, Launchpad, 14/20 Pin DIP Socket, LED's

Technical Data Sheet (809.88KB) EN 모든 기술 문서 보기

이미지는 참고용으로만 제공됩니다. 자세한 내용은 제품 설명을 참조하세요.


제품 개요

MSP-EXP430G2 Launch Pad is easy-to-use Flash programmer and debugging tool for the MSP430G2xx Value Line microcontrollers. It features everything users need to start developing on an MSP430 microcontroller device. It has on-board emulation for programming and debugging and features a 14/20 pin DIP socket, on-board buttons and LEDs & Booster Pack-compatible pinouts that support a wide range of plug-in modules for added functionality.
  • Enables development on any MSP430 Value Line device with 14- or 20 pin DIP (N) packages
  • LaunchPad's integrated emulator interface connects Flash based MSP430 Value Line devices to a PC
  • Includes one mini USB cable to interface with a PC.
  • Included MSP430G2xx devices feature preloaded sample programs.
  • Free downloadable versions of IAR Kick-start and Code Composer Studio Version 5
  • 2 programmable LEDs, 1 power LED, 1 programmable button, 1 reset button
  • Built-in Flash emulation for debugging and programming
  • 10pin PCB connector
  • RoHS compliant

제품 정보

Core Architecture:
Core Sub-Architecture:
Integrated USB-powered Flash Emulation Tool
Kit Contents:
LaunchPad Emulator, Mini USB-B Cable, Quick Start Guide
Kit Features:
Built-in Flash Emulation for Debugging and Programming, 14/20-pin DIP (N) Socket
No. of Bits:
Product Range:
No SVHC (15-Jun-2015)
Silicon Core Number:
Silicon Family Name:
Silicon Manufacturer:
Texas Instruments

유사 제품 찾기  공통 특성별 분류


  • Power Management;
  • Sensing & Instrumentation;
  • Embedded Design & Development


MSP430G2553IN20 Flash device (preloaded with sample program10 pin PCB Connector (2 male/2 female) 32KHz crystal, Launch Pad Development board (MSP-EXP430G2), Launch Pad sticker, Mini USB cable, Quick Start Guide

법률 및 환경

United States

최종후의 중요 제조 공정이 이루어진 국가

관세 번호:

관련 제품

유사 제품

이 제품과 기능적으로 유사한 제품을 찾을 수 있습니다. 다음 링크 중 하나를 선택하면 이 카테고리의 모든 제품 중 지정된 특성을 공유하는 제품이 나열된 제품 그룹 페이지가 표시됩니다.

  • Kit Contents: LaunchPad Emulator, Mini USB-B Cable, Quick Start Guide
  • Silicon Core Number: MSP430
  • No. of Bits: 16bit
  • Core Architecture: MSP430
  • Silicon Family Name: MSP430G2xx
  • Product Range: -
  • Core Sub-Architecture: MSP430
  • Silicon Manufacturer: Texas Instruments
