CPX200D

The CPX200D replaces the best-selling CPX200. A wider PowerFlex range extends maximum voltage from 35 volts to 60 volts, whilst the maximum current of 10 amps is now available up to 16 volts rather than 12 volts. New features include S-Lock, Range Control, Voltage Tracking and Synchronous On/Off.

• PowerFlex design gives variable voltage and current combinations within a maximum power envelope
• Up to 60V and up to 10A maximum per output (180W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Independent outputs or isolated voltage tracking
• Outputs can be wired in series or parallel for 120V or 20A
• Variable OVP trips, safety binding-post terminals
• 4 digit fixed resolution meters, selectable remote sensing
• Compact ½ rack 3U case for bench use or rack mounting
• No Interfaces
• UK mains plug (type G), as used in the UK, IRL, Cyprus, Saudi Arabia, Malta and many others.

애플리케이션

Power Management, Test & Measurement

메모

In addition, we have calibration services for this product (Europe Only). Visit our calibration service page to see details of what options are available.
