5747840-6
D Sub Connector, DB9, Standard, Plug, AMPLIMITE HD-20, 9 Contacts, DE, Solder
더 필요하세요?
| 수량 | 가격 |
|---|---|
| 1+ | ₩5,020 |
| 25+ | ₩4,919 |
| 75+ | ₩4,775 |
| 200+ | ₩4,641 |
| 400+ | ₩4,508 |
제품 정보
제품 개요
The 5747840-6 is a 9-way 2-row front metal shell D-sub Plug with gold-plated brass contacts and fixed clear chromate-plated zinc female screwlocks. The Amplimite HD-20 series right angle posted plug comes with grounding indents, grounding straps, black nylon/polyester housing, tin-plated brass eyelet, tin-plated carbon steel shell and tin-plated solder tail. Plugs are preloaded with size 20 DF posted pin contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308. The front metal-shell design is compatible with full metal-shell connectors.
- UL94V-0 Flammability rating
- Right angle through hole PCB mounting
- Copper alloy boardlock
애플리케이션
Industrial, Computers & Computer Peripherals
기술 사양
Standard
AMPLIMITE HD-20
DE
Through Hole Mount Right Angle
Gold Plated Contacts
No SVHC (21-Jan-2025)
Plug
9Contacts
Solder
Brass
Metal Body
5747840-6의 대체 제품
8개 제품을 찾았습니다.
관련 제품
8개 제품을 찾았습니다.
법률 및 환경
최종후의 중요 제조 공정이 이루어진 국가원산지:Mexico
최종후의 중요 제조 공정이 이루어진 국가
RoHS
RoHS
제품 준수 증명서
