EVAL-ADM2461EEBZ

EVAL-ADM2461EEBZ is a simplified, efficient evaluation of the ADM2461E 500KBPS, 5.7K VRMS, signal isolated, half-duplex RS-485 transceiver with ±15KV IEC ESD. The EVAL-ADM2461EEBZ comes with options for the evaluation of the ADM2461E in an individual system. Digital and RS485 bus signals are easily accessible via the screw terminal blocks on the EVAL-ADM2461EEBZ. Each digital input can be configured via the on-board jumper options.

• Simplified evaluation of the ADM2461E signal isolated 500Kbps half-duplex RS-485 transceiver
• 2-layer PCB compliant with EN 55032 Class B radiated emissions
• 2 on-board ADP7104 LDO regulators with jumper for simplified evaluation in multiple supply config
• Jumper to utilize flexible, VDD1 low voltage supply rail for interfacing with I/O node as 1.7V
• SMA connector for TxD input signal
• Optional on-board LTC1799 oscillator for providing TxD signal
• Screw terminal blocks for connecting power, digital and RS-485 signals
