FLUKE 1503

FLUKE 1503 is a battery powered insulation resistance meter handles all the basic insulation testing needs. The Fluke 1503 is a great choice for basic residential and commercial electrical insulation testing. This rugged, compact tool fits in the palm of your hand.

• Measures AC/DC voltage from 0.1V to 600V, measures resistance from 0.01ohm to 20.00Kohm
• Performs insulation tests from 0.01Mohm to 2000Mohm, two insulation test voltages: 500V and 1000V
• Includes auto-discharge of capacitive voltage for added user protection
• Provides lo-ohms earth-bond continuity (200 mA)
• Simplifies repetitive or hard-to-reach testing with the remote test probe
• Saves battery power with auto power off
• Presents results on a large, backlit display
• Features CAT IV 600V overvoltage category rating
• Accepts optional Fluke TPAK magnetic hanging system to free your hands for other work
• Runs on four AA alkaline batteries (NEDA 15 A or IEC LR6) for at least 1000 insulation tests

목차

Insulation resistance tester, Remote probe, Test leads, Test probes, Alligator clips, User documentation, One-year warranty.

메모

Get a FREE Fluke tool on spend of £100+ (excl. VAT)in EMEA only, until 31/12/2026 (Discover more: https://www.farnell.com/datasheets/4800832.pdf). Calibration services are available (Europe only). Please visit our calibration services page for more details.
