제품 정보
제조업체IDEAL POWER
제조업체 부품 번호77DB-06-12
주문 코드2368011
기술 데이터 시트
Power Supply ApplicationsITE
No. of Outputs1 Output
Output Power6W
Output Power Max6W
Output Voltage VAC12VAC
Output Current500mA
Plug TypeUK Type G
Output Connector2.1mm x 5.5mm x 12mm
Input Voltage AC Max240VAC
Power Supply Output TypeFixed
Product Range-
SVHCNo SVHC (21-Jan-2025)
제품 개요
The 77DB-06-12 is a 12VAC/10W UK plug-in linear AC to AC Power Supply is a lightweight, with one-shot thermal fuse protection, UL94V-0 rated enclosure, 3-pin input cable, 6 to 7VA output power and 1 minute test time.
- Class-B insulation
- 80% Efficiency
- -10 to 40°C Operating temperature range
- Meets efficiency Level VI and (EU) 2019/1782
- 1.8m cable with 2.5mm barrel connection
- Approved to UKCA, CE, TUV, RoHS, and REACH
애플리케이션
Power Management
메모
As with all AC/AC linear power supplies and transformers, the output voltage is influenced by both the applied load and AC mains supply voltage
기술 사양
Power Supply Applications
ITE
Output Power
6W
Output Voltage VAC
12VAC
Plug Type
UK Type G
Input Voltage AC Max
240VAC
Product Range
-
No. of Outputs
1 Output
Output Power Max
6W
Output Current
500mA
Output Connector
2.1mm x 5.5mm x 12mm
Power Supply Output Type
Fixed
SVHC
No SVHC (21-Jan-2025)
기술 문서 (1)
관련 제품
4개 제품을 찾았습니다.
법률 및 환경
원산지:
최종후의 중요 제조 공정이 이루어진 국가원산지:China
최종후의 중요 제조 공정이 이루어진 국가
최종후의 중요 제조 공정이 이루어진 국가원산지:China
최종후의 중요 제조 공정이 이루어진 국가
관세 번호:85044095
US ECCN:EAR99
EU ECCN:NLR
RoHS 준수:예
RoHS
RoHS 프탈레이트 준수:예
RoHS
SVHC:No SVHC (21-Jan-2025)
제품 준수 증명서 다운로드
제품 준수 증명서
무게(kg):.285
