TEN 40-2412WIR
Isolated Through Hole DC/DC Converter, ITE & Railway, DIP, 4:1, 40 W, 1 Output, 12 V
10 지금 제품을 예약하실 수 있습니다
| 수량 | 가격 |
|---|---|
| 1+ | ₩143,896 |
| 10+ | ₩136,282 |
| 25+ | ₩127,262 |
| 50+ | ₩120,902 |
| 100+ | ₩119,711 |
제품 정보
제품 개요
The TEN 40-2412WIR is a high performance 40W DC/DC Converter Module featuring ultra wide 4:1 input voltage range of 9 to 36VDC with industry-standard footprint. Input voltages up to 160 VDC, excellent EMC characteristics and EN 50155 approval make this device the best choice for many demanding applications in railroad and transportation systems. Further standard features include 12VDC output voltage, remote ON/OFF, overvoltage protection, under-voltage lockout and short-circuit protection. Low input current characteristics at minimal load make this converter also the ideal solution for battery-operated systems.
- No minimum load required
- Output voltage adjustable
- Thermal shock and vibration resistant according EN 61373
- 91% Typical efficiency
- 24VDC Nominal input voltage
애플리케이션
Wireless, Communications & Networking, Automation & Process Control, Test & Measurement
기술 사양
ITE & Railway
4:1
1 Output
3.333A
-
1.5kV
Fixed
10.2mm
9V
TEN 40WIR Series
DIP
40W
12V
-
-
24V
25.4mm
50.8mm
36V
No SVHC (14-Jun-2023)
관련 제품
4개 제품을 찾았습니다.
법률 및 환경
최종후의 중요 제조 공정이 이루어진 국가원산지:Taiwan
최종후의 중요 제조 공정이 이루어진 국가
RoHS
RoHS
제품 준수 증명서
