278-401-000
Multipair Cable, Audio, Per M, Screened, 1 Pair, 24 AWG, 0.22 mm²
입고 시 알림 요청
| 수량 | 가격 |
|---|---|
| 1+ | ₩80,328 |
제품 정보
제품 개요
The 278-401-000 is a 2-conductor shielded Digilog Ecoflex AES/analogue Installation Cable with bare ultra-pure oxygen-free copper conductor of 24AWG wire with purple SHF-1 LSZH polymer Red Lilac RAL 4001 jacket of 0.5mm thickness, 3.9mm diameter. Purple Series Digilog Ecoflex is a low smoke zero halogen (LSZH) jacketed audio multicore specifically for installation use. The use of LSZH cables is becoming a specified essential in public buildings and new build construction projects. Based electrically and mechanically on the Van Damme Green Series range this cable will carry AES/EBU and/or analogue balanced audio as well as paired data signals such as RS485, RS422 and DMX512.
- CPR: Not Yet Qualified
- <gt/>9N/mm² Tensile strength (jacket)
- <lt/>90Ω/km conductor resistance
- <gt/>5000MΩ/km Insulation resistance
- 50pF/m Core to core nominal capacitance
애플리케이션
Audio, Communications & Networking, Building Automation, Industrial
기술 사양
Screened
24AWG
-
Purple
500V
Copper
Purple Series
1 Pair
0.22mm²
-
7 x 0.2mm
LSZH
3.9mm
No SVHC (17-Dec-2015)
기술 문서 (1)
278-401-000의 대체 제품
1개 제품을 찾았습니다.
관련 제품
5개 제품을 찾았습니다.
법률 및 환경
최종후의 중요 제조 공정이 이루어진 국가원산지:Italy
최종후의 중요 제조 공정이 이루어진 국가
RoHS
제품 준수 증명서
